STEEL
DESIGN
& Support
Get expert drawing packs for all your fabrication needs. Plus, our design services are tailored specifically with all the support you need to save you time and money, so you can be confident that you’re getting the best possible value for your investment.
DESIGN CATEGORIES
Metalworks
Structural Steel
Design Process
Providing you with a customised service that meets your specific needs
Specifications
We’ll work directly with you and your architect, engineer, or client to make sure that all the specifications are accurately collected.
Surveying
Attending site surveys to ensure the full scope of specification requirements match your needs.
Drawing Production
When the review process is completed and all comments have been incorporated into the final design, we’ll produce fabrication drawings.
Fabrication Drawing Types
Assembly Drawings
Part Drawings
Dxf Files
NC Files
Erection Drawings
Draughting & Review
Once we have all information from specification and survey 3D model designs begin and GA drawings will be sent for review and approval.
It’s all part of the service
Multiple Revisions
Site Visits - Surveying
Post Design Completion Support
Fabrication guidance
Installation Support
in the last 12 months
How do you measure success? For us, it’s all about the satisfaction of our clients who are on tight deadlines to get what they want – their projects finished the way it should be!
The following are just a few of the milestones we achieved this past year.
Projects
METALWORK METRES
TONNES OF STEEL
We’re proud to offer our clients with a customised service that meets their specific needs. Whatever the design we’ll work closely with you to ensure that the final product is exactly what you need to get your project done.
WE'RE HERE TO HELP YOU
Tell us what your project needs are today
